MODEL

60K

80K

100K

120K

180K

200K

240K

300K

PHASE

3-phasein/3-phaseout

CABINETCAPACITY

60KVA/60KW

80KVA/80KW

100KVA/100KW

120KVA/120KW

180KVA/180KW

200KVA/200KW

240KVA/240KW

300KVA/300KW

BATTERYTYPE

ExternalBattery

PARALLELCAPABILITY

4

2

INPUT

NominalVoltage

3x380/400/415VAC(3Ph+N)

VoltageRange

110-300VAC@50%load;184-276VAC@100%load

NominalFrequency

50/60Hz(Auto sensing)

Frequency Range

40Hz ~70Hz

Power Factor

≧0.99@100% load

HarmonicDistortion(THDi)

<5%atfulllinear load

<4%atfulllinear load

OUTPUT

NominalVoltage

3x380/400/415VAC(3Ph+N)

VoltageRegulation(Steadystate)

≦±1%Typical(balancedload)

≦±2%Typical(unbalancedload)

NominalFrequency

50/60Hz

FrequencyRange(Synchronizedrange)

46Hz ~ 54Hz or 56Hz ~ 64Hz

OverloadCapability

≦110%for1hour,111%~125%for10mins,126%~150%for1minand>150%for200ms

Harmonic Distortion

≦2%THD(LinearLoad);≦4%THD(Non-linearLoad)
