Operating voltage

DC 8V to 36V continuous power supply

Overall power consumption

Standby : MAX 2W Operating : MAX 3W

Engine speed signal range

50-10000 Hz ( AC1 ~ 70 V)

Maximum cumulative running time

99999.9 hours ( minimum storage time 6 minutes )

Motor output

Max 5 Amp/250V AC passive contact normally open output

Configurable relays 1-5

Max 5 Amp/250V AC passive contact normally open output

Configurable relays 6

Max 3 Amp/250V AC passive contact normally open and normally closed output

Excitation output

DC +VE power supply voltage output

Sensor input

6 configurable sensor inputs

Configurable input 1-6

Connecting to the negative terminal of the battery is effective

Working conditions

- 25 - 65 ℃

Storage conditions

-40-80 ℃​​​

Protection level

IP 65 : When a waterproof ring is installed between the controller and the control panel.

Insulation class

When an AC 2.2kV voltage is applied between the high-voltage and low-voltage terminals , the leakage current should not exceed 3mA within 1 minute .

External dimensions

142 mm*1 105 mm * 45 mm

Opening size

1 16 mm * 90 mm

weight

0.35 Kg
