Operating voltage

DC9V to 36V continuous power supply

Overall power consumption

Standby: 24V: MAX 2W

Operating voltage: 24V: MAX 5W

AC voltage input

One phase, two wires, 30VAC-276VAC (ph-N)

Two-phase three-wire 30VAC-276VAC (ph-N)

Three-phase four-wire 30VAC-276VAC (ph-N)

Engine speed signal range

1-10000Hz

Maximum cumulative running time

9,999,999.9 hours (minimum storage time 6 minutes)

Fuel output

Max 16Amp DC +VE power supply voltage output

Motor output

Max 16Amp DC +VE power supply voltage output

Configurable relay 1

Max 5Amp DC +VE power supply voltage output

Configurable relay 2

Max 5Amp DC +VE power supply voltage output

Configurable relay 3

Max 5Amp DC +VE power supply voltage output

Configurable relays 4

Max 5Amp/250V Passive Contact Normally Open-Normal Closed Output

Configurable relay 5

Max 5Amp/250V Passive Contact Normally Open-Normal Closed Output

Configurable relays 6

Max 5Amp/250V passive contact normally open output

Excitation output

Maximum 0.9Amp DC +VE power supply voltage output

Configurable input

Connecting to the negative terminal of the battery is effective

Working conditions

-30-70℃

Storage conditions

-40-85℃

Protection level

IP65: When a waterproof ring is installed between the controller and the control panel.

Insulation class

When an AC 2.2kV voltage is applied between the high-voltage and low-voltage terminals , the leakage current should not exceed 3mA within 1 minute .

External dimensions

241mm*177mm*45mm

Opening size

220mm*160mm

weight

1Kg
